Produk

Penumbu

Standar: DIN7603
Komoditas: Penumbu
Taler Named: DIN 7603 Gasket
Materi: Baja
Diameter: M2/ M2,5/ M3/ M3/ M3/ M4/ M6/ M6/ M8/ M10/ M14/ M16/ M18/ M20/ M20/ M27/ M20/ M36/ M48/ M46/ M70/ M70/ M90/ M90/ M90/ M90/ M40/
Puput: Dataran, Hitam, Seng Sane Magenah, Dippled Galvanis, Oksidasi, Dakrom, Fosfat, Cadmium Elektroplate, Nikel Genahang
MOQ: 1000kgs
Galah Tiri: 30 ngantos 60 rahina

Ngirim penyelidikan

Purwaka Produk

AYA Fasteners (Hebei) Co., Ltd inggih punika silih sinunggil produsen lan pemasok sane pinih berpengalaman saking pencuci segel logam ring Cina. In Balinese : Ngiring bebas numbas cuci penyegelan logam sane berkualitas tinggi sane kakaryanin ring Cina iriki saking pabrik iraga. Antuk konsultasi harga, hubungi titiang.

Metal Sealing Washers-AYA

Pinaka pemasok global saking solusi pengendapan khusus, proses penangkapan AYA taler sekadi nampek sareng pelanggan sekadi produk AYA. Saking nlatarang kabuatang nginutin layanan -py layanan, AYA pacang gelis lan nenten nglukat utsaha anggen ngwantu pelanggan muputang pikobet pengendapan napi-napi sane metu, anggen ngicalang rasa jejeh ring pelanggan.

Deskripsi Produk

Wastan Produk	Penumbu
Taler sane kawastanin	DIN 7603 Kasketsi
Bahan	Waja
Standar	DIN7603
Diametere	Φ4×8, Φ5×7.5, Φ5.5×8, Φ6.5×9.5, Φ7×15, Φ8×11.5, Φ10×13.5, Φ12×15.5, Φ12×16, Φ12×19, Φ14×18, Φ14×20, Φ15×19, Φ15×23, Φ16×20, Φ17×21, Φ18×22, Φ20×24, Φ21×26, Φ22×27, Φ23×28, Φ24×29, Φ25×30, Φ26×31, Φ27×32, Φ28×33, Φ30×36, Φ32×38, Φ33×39, Φ35×41, Φ36×42, Φ38×44, Φ39×46, Φ40×47, Φ42×49, Φ44×51, Φ45×52, Φ48×55, Φ50×57, Φ52×60, Φ54×62, Φ55×63, Φ56×64, Φ58×66, Φ60×68, Φ64×72, Φ65×74, Φ70×79, Φ75x84, Φ78×88, Φ80×90, Φ85×95, Φ90×100
Pragat	Pola, Hitam, Seng Genahang, Dippled Galvanis, Oksidasi, Dakrom, Fosfat, Kadmium Listroplate, Nikel Sane Kagenahang

Ukuran			Φ4×8	Φ5×7.5	Φ5.5×8	Φ6.5×9.5	Φ7×15	Φ8×11.5	Φ10×13.5	Φ12×15.5	Φ12×16	Φ12×19
Ukuran			Φ4×8	Φ5×7.5	Φ5.5×8	Φ6.5×9.5	Φ7×15	Φ8×11.5	Φ10×13.5	Φ12×15.5	Φ12×16	Φ12×19
d	min{{0} ukuran nominal		4.2	5.2	5.7	6.7	7.2	8.2	10.2	12.2	12.2	12.2
d	maks		4.5	5.5	6	7	7.5	8.5	10.5	12.5	12.5	12.5
dc	max{{0} ukuran nominal		7.9	7.4	7.9	9.4	14.9	11.4	13.4	15.4	15.9	18.9
dc	min		7.7	7.2	7.7	9.2	14.7	11.2	13.2	15.2	15.7	18.7
L	Al,St,Cu,Vf,Zn	Ukuran Nominal	1	1	1	1	1.5	1	1	1.5	1.5	1.5
		maks	1.2	1.2	1.2	1.2	1.7	1.2	1.2	1.7	1.7	1.7
		min	0.8	0.8	0.8	0.8	1.3	0.8	0.8	1.3	1.3	1.3
	1	Ukuran Nominal	1	1	1	1	1	1	1	1.5	1.5	1.5
		maks	1.2	1.2	1.2	1.2	1.2	1.2	1.2	1.65	1.65	1.65
		min	0.8	0.8	0.8	0.8	0.8	0.8	0.8	1.35	1.35	1.35
	barang Prg	Ukuran Nominal	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5
		maks	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6
		min	0.4	0.4	0.4	0.4	0.4	0.4	0.4	0.4	0.4	0.4
	A Pr		0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3
per 1000 unit≈g	±25%	1	0.066	0.039	0.043	0.063	0.373	0.092	0.111	0.195	0.23	0.461
		Vfy	0.036	0.022	0.024	0.035	0.228	0.051	0.062	0.107	0.126	0.282
		barang Prg	0.017	0.01	0.011	0.016	0.113	0.023	0.028	0.033	0.038	0.139
		A Pr	0.01	0.006	0.007	0.01	0.069	0.014	0.017	0.02	0.023	0.085
		Al	0.089	0.053	0.058	0.085	0.559	0.124	0.15	0.264	0.311	0.691
		Jl	0.259	0.155	0.168	0.247	1625	0.362	0.435	0.767	0.905	2.01
		Cu	0.294	0.176	0.191	0.28	1.842	0.412	0.493	1.87	1.03	2.28
		Zn	-	-	-	-	1.478	-	-	-	-	1.828
Ukuran			Φ14×18	Φ14×20	Φ15×19	Φ15×23	Φ16×20	Φ17×21	Φ18×22	Φ20&×24	Φ21×26	Φ22×27
Ukuran			Φ14×18	Φ14×20	Φ15×19	Φ15×23	Φ16×20	Φ17×21	Φ18×22	Φ20&×24	Φ21×26	Φ22×27
d	min{{0} ukuran nominal		14.2	14.2	15.2	15.2	16.2	17.2	18.2	20.2	21.2	22.2
d	maks		14.5	14.5	15.5	15.5	16.5	17.5	18.5	20.5	21.5	22.5
dc	max{{0} ukuran nominal		17.9	19.9	18.9	22.9	19.9	20.9	21.9	23.9	25.9	26.9
dc	min		17.7	19.7	18.7	22.7	19.7	20.7	21.7	23.7	25.7	26.7
L	Al,St,Cu,Vf,Zn	Ukuran Nominal	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5
		maks	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7
		min	1.3	1.3	1.3	1.3	1.3	1.3	1.3	1.3	1.3	1.3
	1	Ukuran Nominal	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5
		maks	1.65	1.65	1.65	1.65	1.65	1.65	1.65	1.65	1.65	1.65
		min	1.35	1.35	1.35	1.35	1.35	1.35	1.35	1.35	1.35	1.35
	barang Prg	Ukuran Nominal	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5
		maks	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6
		min	0.4	0.4	0.4	0.4	0.4	0.4	0.4	0.4	0.4	0.4
	A Pr		0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3
per 1000 unit≈g	±25%	1	0.264	0.44	0.28	0.644	0.3	0.32	0.328	0.36	0.5	0.522
		Vfy	0.145	0.242	0.154	0.394	0.165	0.176	0.18	0.198	0.275	0.288
		barang Prg	0.045	0.074	0.047	0.195	0.05	0.053	0.055	0.06	0.083	0.087
		A Pr	0.027	0.044	0.028	0.119	0.03	0.032	0.033	0.036	0.05	0.052
		Al	0.356	0.595	0.378	0.967	0.403	0.433	0.444	0.488	0.675	0.705
		Jl	1.03	1.73	1.1	2.81	1.179	1.26	1.29	1.42	1.96	2.05
		Cu	1.17	1.96	1.25	3.19	1.33	1.43	1.46	1.16	2.22	2.32
		Zn	-	1.71	-	2.556	-	-	-	-	-	-
Ukuran			Φ23×28	Φ24×29	Φ25×30	Φ26×31	Φ27×32	Φ28×33	Φ30×36	Φ32×38	Φ33×39	Φ35×41
Ukuran			Φ23×28	Φ24×29	Φ25×30	Φ26×31	Φ27×32	Φ28×33	Φ30×36	Φ32×38	Φ33×39	Φ35×41
d	min{{0} ukuran nominal		23.3	24.3	25.3	26.3	27.3	28.3	30.3	32.3	33.3	35.3
d	maks		23.6	24.6	25.6	26.6	27.6	28.6	30.6	32.6	33.6	35.6
dc	max{{0} ukuran nominal		27.9	28.9	29.9	30.9	31.9	32.9	35.9	37.9	38.9	40.9
dc	min		27.7	28.7	29.7	30.7	31.7	32.7	35.7	37.7	38.7	40.7
L	Al,St,Cu,Vf,Zn	Ukuran Nominal	2	2	2	2	2	2	2	2	2	2
		maks	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2
		min	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8
	1	Ukuran Nominal	2	2	2	2	2	2	2	2	2	2
		maks	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2
		min	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8
	barang Prg	Ukuran Nominal	1	1	1	1	1	1	1	1	1	1
		maks	1.15	1.15	1.15	1.15	1.15	1.15	1.15	1.15	1.15	1.15
		min	0.85	0.85	0.85	0.85	0.85	0.85	0.85	0.85	0.85	0.85
	A Pr		0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3
per 1000 unit≈g	±25%	1	0.705	0.733	0.765	0.793	0.815	0.845	1.13	1.2	1.24	1.3
		Vfy	0.386	0.403	0.422	0.435	0.45	0.463	0.62	0.655	0.673	0.713
		barang Prg	0.177	0.184	0.19	0.197	0.204	0.212	0.28	0.298	0.305	0.323
		A Pr	0.054	0.055	0.057	0.059	0.062	0.064	0.084	0.09	0.092	0.097
		Al	0.95	0.99	1.03	1.07	1.1	1.14	1.52	1.6	1.65	1.74
		Jl	2.77	2.88	2.99	3.1	3.21	3.31	4.41	4.66	4.8	5.07
		Cu	3.24	3.26	3.4	3.51	3.64	3.75	5	5.27	5.44	5.73
		Zn	-	-	-	-	-	-	-	-	-	-
Ukuran			Φ36×42	Φ38×44	Φ39×46	Φ40×47	Φ42×49	Φ44×51	Φ45×52	Φ48×55	Φ50×57	Φ52×60
Ukuran			Φ36×42	Φ38×44	Φ39×46	Φ40×47	Φ42×49	Φ44×51	Φ45×52	Φ48×55	Φ50×57	Φ52×60
d	min{{0} ukuran nominal		36.3	38.3	39.3	40.3	42.3	44.3	45.3	48.3	50.2	52.5
d	maks		36.6	38.6	39.6	40.6	42.6	44.6	45.6	48.6	50.5	53
dc	max{{0} ukuran nominal		41.9	43.9	45.9	46.9	48.9	50.9	51.9	54.9	56.9	59.8
dc	min		41.7	43.7	45.7	46.7	48.7	50.7	51.7	54.7	56.7	59.5
L	Al,St,Cu,Vf,Zn	Ukuran Nominal	2	2	2	2	2	2	2	2	2	2.5
		maks	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.7
		min	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	2.3
	1	Ukuran Nominal	2	2	2	2	2	2	2	2	2	2
		maks	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2
		min	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8
	barang Prg	Ukuran Nominal	1	1	1	1	1	1	1	1	1	1.5
		maks	1.15	1.15	1.15	1.15	1.15	1.15	1.15	1.15	1.15	1.7
		min	0.85	0.85	0.85	0.85	0.85	0.85	0.85	0.85	0.85	1.3
	A Pr		0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3
per 1000 unit≈g	±25%	1	1.34	1.41	1.74	1.76	1.83	1.91	1.95	2.07	2.15	2.9
		Vfy	0.732	0.767	0.943	0.966	1.02	1.06	1.08	1.14	1.18	1.6
		barang Prg	0.332	0.348	0.428	0.438	0.457	0.478	0.479	0.518	0.54	0.87
		A Pr	0.1	0.104	0.128	0.132	0.138	0.144	0.144	0.156	0.162	0.174
		Al	1.79	1.88	2.32	2.37	2.47	2.58	2.64	2.8	2.9	3.85
		Jl	5.2	5.47	6.73	6.88	7.2	7.5	7.67	8.15	8.45	11.4
		Cu	5.88	6.15	6.96	7.8	8.15	8.5	8.68	9.23	9.56	12.9
		Zn	-	-	-	-	-	-	-	-	-	-
Ukuran			Φ54×62	Φ55×63	Φ56×64	Φ58×66	Φ60×68	Φ64×72	Φ65×74	Φ70×79	Φ75×84	Φ78×88
Ukuran			Φ54×62	Φ55×63	Φ56×64	Φ58×66	Φ60×68	Φ64×72	Φ65×74	Φ70×79	Φ75×84	Φ78×88
d	min{{0} ukuran nominal		54.5	55.5	56.5	58.5	60.5	64.5	65.5	70.5	75.5	78.5
d	maks		55	56	57	59	61	65	66	71	76	79
dc	max{{0} ukuran nominal		61.8	62.8	63.8	65.8	67.8	71.8	73.8	78.8	83.8	87.8
dc	min		61.5	62.5	63.5	65.5	67.5	71.5	73.5	78.5	83.5	87.5
L	Al,St,Cu,Vf,Zn	Ukuran Nominal	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5	2.5
		maks	2.7	2.7	2.7	2.7	2.7	2.7	2.7	2.7	2.7	2.7
		min	2.3	2.3	2.3	2.3	2.3	2.3	2.3	2.3	2.3	2.3
	1	Ukuran Nominal	2	2	2	2	2	2	2	2	2	2
		maks	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2	2.2
		min	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8	1.8
	barang Prg	Ukuran Nominal	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5
		maks	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7
		min	1.3	1.3	1.3	1.3	1.3	1.3	1.3	1.3	1.3	1.3
	A Pr		0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3
per 1000 unit≈g	±25%	1	3	3.11	3.14	3.22	3.32	3.52	3.58	4.68	5	5.86
		Vfy	1.67	1.72	1.75	1.77	1.83	1.94	1.97	2.58	2.76	3.22
		barang Prg	0.9	0.93	0.942	0.965	1	1.05	1.07	1.4	1.5	1.76
		A Pr	0.18	0.186	0.187	0.193	0.2	0.213	0.214	0.28	0.3	0.352
		Al	4.06	4.2	4.3	4.35	4.48	4.8	4.83	6.35	6.75	7.9
		Jl	11.8	12.2	12.3	12.6	13	13.85	14	18.4	19.6	23
		Cu	13.4	13.8	13.95	14.3	14.8	15.7	15.9	20.9	22.3	26.1
		Zn	-	-	-	-	-	-	-	-	-	-
Ukuran			Φ80×90	Φ85×95	Φ90×100	-	-	-	-	-	-	-
Ukuran			Φ80×90	Φ85×95	Φ90×100	-	-	-	-	-	-	-
d	min{{0} ukuran nominal		80.7	85.7	90.7	-	-	-	-	-	-	-
d	maks		81.2	86.2	91.2	-	-	-	-	-	-	-
dc	max{{0} ukuran nominal		89.8	94.8	99.8	-	-	-	-	-	-	-
dc	min		89.5	94.5	99.5	-	-	-	-	-	-	-
L	Al,St,Cu,Vf,Zn	Ukuran Nominal	2.5	2.5	2.5	-	-	-	-	-	-	-
		maks	2.7	2.7	2.7	-	-	-	-	-	-	-
		min	2.3	2.3	2.3	-	-	-	-	-	-	-
	1	Ukuran Nominal	2	2	2	-	-	-	-	-	-	-
		maks	2.2	2.2	2.2	-	-	-	-	-	-	-
		min	1.8	1.8	1.8	-	-	-	-	-	-	-
	barang Prg	Ukuran Nominal	1.5	1.5	1.5	-	-	-	-	-	-	-
		maks	1.7	1.7	1.7	-	-	-	-	-	-	-
		min	1.3	1.3	1.3	-	-	-	-	-	-	-
	A Pr		0.3	0.3	0.3	-	-	-	-	-	-	-
per 1000 unit≈g	±25%	1	5.95	6.25	6.61	-	-	-	-	-	-	-
		Vfy	3.25	3.43	3.63	-	-	-	-	-	-	-
		barang Prg	1.79	1.88	2	-	-	-	-	-	-	-
		A Pr	0.358	0.376	0.4	-	-	-	-	-	-	-
		Al	8	8.45	8.95	-	-	-	-	-	-	-
		Jl	23.1	24.5	25.9	-	-	-	-	-	-	-
		Cu	26.3	27.8	29.5	-	-	-	-	-	-	-
		Zn	-	-	-	-	-	-	-	-	-	-

Rincian Produk

Metal Sealing Washers-detail

Keuntungan Produk

Metal Sealing Washers-advantages

Kautamaan DIN 7603 Washer sane mailehan

1. Logam-to{2}} kontak logam ngicenin kontrol torsi lan penampilan sane sampun puput.

2. Usus penyegelan logam dados kaanggen nyegel unsur sane nglawan kerusakan eksternal.

3. DIN 7603 paking sane kakaryanin antuk cairan utawi gas utawi gas sane tegeh.

4. mesin cuci penyegelan DIN 7603 kaanggen nyegel ring jero lan ring jaba cairan, gas, padatan lan debu.

5. Usus sane malayar wenten antuk sekrup standar lan baut.

Inspeksi Kualitas

Metal Sealing Washers-check

Inspektur QC sampun madue pengalaman sane becik ring kaweruhan produk taler teknik manufaktur. Instrumen khusus sane kaanggen ngamargiang makudang-kudang tes mangda produk akhir prasida nagingin persyaratan pasar lan pelanggan.

Paket & Penguatan Wadah

Metal Sealing Washers-package

Kemasan punika prasida kaadaptasi manut ring kabutuhan pelanggan. Lan pacang jangkep kakukuhang mangda nenten wenten kerusakan sane nenten kajangka rikala kiriman.

Sistem pergudangan lan logistik sane dewasa, lan alat digital ngawinang barang-barang punika prasida mamargi becik.

Skenarian Panganggén

Metal Sealing Washers-usage

Napi mawinan Milih AYA?

AYA advantage

AYA ngicenin layanan eksklusif majeng ring 1000+ anggota saking sajebag jagat nyabran warsa, antuk sistem solusi layanan rantai sane unik, ragane wantah perlu ngeklik mouse mangda ngamolihang solusi pengikat eksklusif lan nikmatin pintu -to- layanan.
